EM-Tec top reference holders for metallographic mounts

EM-Tec top reference holders have been designed for SEM/EDS/WDS analysis on multiple metallographic and petrographic mounts to ensure the same focus conditions for the SEM and same take-off angle for the X-ray analysis system for all mounts in the holder.

The mounts are placed against three reference lips and secured with screws from the side. The reference lips are only 1mm thick and bevelled to reduce X-ray analysis interference. It is intended for the larger analytical SEMs with a large SEM stage. Made from vacuum grade aluminium with stainless steel screws. One of the positions can be used to hold a calibration standard with pure elements and/or known compounds.

There are three top reference holders for metallographic or petrographic mounts of different sizes:

EM-Tec R6 top reference holder for six of the Ø25mm or 1” (Ø25.4mm) mounts
Consists of a top part only with a thickness of 15mm. With the supplied height extender (10mm high), up to 24mm high samples can be mounted. The mounts are secured from the side by screws.

EM-Tec R4 top reference holder for four of the Ø30mm or 1-1/4” (Ø32mm) mounts
Optional adapter sleeves for Ø 25mm or 1” mounts are available for this holder. The EM-Tec R4 top reference holder consist of two parts: top with reference lips and base with screws to push the mounts. The maximum sample height is 20mm. The mounts are secured with screws and can be pushed up with screws in the base. If reduced height metallographic mounts or thin samples are used, Ø25mm spacer discs can be used to ensure that the mounts are pushed against the reference lips. Pushing from the base allows for small angle adjustment if the polished surfaces of mounts are not perfectly perpendicular to the sides. The EM-Tec R4 holder can also be used without the base on the EM-Tec stage adapters with an M4 screw.

Top reference holder EM-Tec 12 for two of the Ø25mm or Ø 1” mounts
The EM-Tec R12 top reference holder consist of two parts: top and base. The maximum sample height is 20mm. The mounts are secured with screws and can be pushed against the reference lips with screws in the base. If reduced height metallographic mounts or thin samples are used, Ø25mm spacer discs can be used under the mount. Pushing from the base allows for small angle adjustment if the polished surfaces of mounts are not perfectly perpendicular to the sides. The top of the EM-Tec R12 can be used without the base on the EM-Tec stage adapters with an M4 screw.

Top reference holders EM-Tec R14 for four of the Ø25mm or Ø 1” mounts
The EM-Tec R14 has the same design as the EM-Tec R12 top reference holder, but double the capacity: 4 x Ø25mm or 4 x 1” metallographic mounts

Top reference holders EM-Tec R2 for two of the Ø40mm and EM-Tec R2-1.5 for two of the Ø 1-1/2” (Ø38mm) mounts
The EM-Tec R2 and R2-1.5 top reference holders consist of two parts: top and base. The maximum sample height is 20mm. The mounts are secured with screws and can be pushed up with screws in the base. If reduced height metallographic mounts or thin samples are used, Ø32mm spacer discs can be used to ensure that the mounts are pushed against the reference lips. Pushing from the base allows for small angle adjustment if the polished surfaces of mounts are not perfectly perpendicular to the sides. The EM-Tec R2 and R2-1.5 top reference holders include two positions for calibration standards mounted on a standard 12.7mm pin stub. The top of the EM-Tec R2 and R2-1.5 holders can also be used without the base on the EM-Tec stage adapters with an M4 screw.

 Top reference holders EM-Tec R22 for four of the Ø40mm and EM-Tec R22-1.5 for four of the Ø 1-1/2” (Ø38mm) mounts
The EM-Tec R22 and R22-1.5 have the same design as the EM-Tec R2 or R2-1.5 top reference holders, but double the capacity: 4 x  Ø40mm or 4 x 1-1/2” metallographic mounts. The EM-Tec R22 and R22-1.5 top reference holders includes four positions for calibration standards mounted on a standard 12.7mm pin stub.

 EM-Tec R5 top reference holder for two of the Ø50mm or 2”  mounts
The EM-Tec R5 top reference holder consist of two parts: top and base. The maximum sample height is 26mm. The mounts are secured with screws and can be pushed up with screws in the base. If reduced height metallographic mounts or thin samples are used, Ø32mm spacer discs can be used to ensure that the mounts are pushed against the reference lips. Pushing from the base allows for small angle adjustment if the polished surfaces of mounts are not perfectly perpendicular to the sides. The EM-Tec R5 top reference holder includes two positions for calibration standards mounted on a standard 12.7mm pin stub. The EM-Tec R5 holder can also be used without the base on the EM-Tec stage adapters with an M4 screw.

 EM-Tec R7 top reference holder for one 49 x 89mm block mount
The EM-Tec R7 top reference holder consist of two parts: top and base. The maximum sample height is 26mm. The mounts are secured with screws and can be pushed up with screws in the base. Pushing from the base allows for small angle adjustment if the polished surfaces of mounts are not perfectly perpendicular to the sides.

Specifications of the EM-Tec top reference holders:

Holder type

Product nr

Mount size

Mounts

Max height

Top / Base

Sample area

Overall size

Stage comp.

EM-Tec R6

12-000259

Ø25mm/ 1”

6

24mm

yes / no

Ø90mm

Ø98mmx25mm

3.2mm pin stub

EM-Tec R6

12-000359

Ø25mm/ 1”

6

24mm

yes / no

Ø90mm

Ø98mmx25mm

M4

EM-Tec R6

12-000659

Ø25mm/ 1”

6

24mm

yes / no

Ø90mm

Ø98mmx25mm

Ø14mm JEOL

EM-Tec R4

12-000255

Ø30mm/ 1-1/4”

4

20mm

yes / yes

68x68mm

Ø96mmx25mm

3.2mm pin stub

EM-Tec R4

12-000355

Ø30mm/ 1-1/4”

4

20mm

yes / yes

68x68mm

Ø96mmx25mm

M4

EM-Tec R4

12-000655

Ø30mm/ 1-1/4”

4

20mm

yes / yes

68x68mm

Ø96mmx25mm

Ø14mm JEOL

EM-Tec R12

12-003212

Ø25mm/ 1”

2

20mm

yes / yes

26x58mm

73x31x26mm

3.2mm pin stub

EM-Tec R12

12-003312

Ø25mm/ 1”

2

20mm

yes / yes

26x58mm

73x31x26mm

M4

EM-Tec R12

12-006212

Ø25mm/ 1”

2

20mm

yes / yes

26x58mm

73x31x26mm

Ø14mm JEOL

EM-Tec R14

12-003214

Ø25mm/ 1”

4

20mm

yes / yes

52x58mm

73x62x30mm

3.2mm pin stub

EM-Tec R14

12-003314

Ø25mm/ 1”

4

20mm

yes / yes

52x58mm

73x62x30mm

M4

EM-Tec R14

12-006214

Ø25mm/ 1”

4

20mm

yes / yes

52x58mm

73x62x30mm

Ø14mm JEOL

EM-Tec R2

12-000252

Ø40mm

2

20mm

yes / yes

88x40mm

103x46x26mm

3.2mm pin stub

EM-Tec R2

12-000352

Ø40mm

2

20mm

yes / yes

88x40mm

103x46x26mm

M4

EM-Tec R2

12-000652

Ø40mm

2

20mm

yes / yes

88x40mm

103x46x26mm

Ø14mm JEOL

EM-Tec R2-1.5

12-003258

Ø1-1/2”

2

20mm

yes / yes

88x38mm

103x46x26mm

3.2mm pin stub

EM-Tec R2-1.5

12-003358

Ø1-1/2”

2

20mm

yes / yes

88x38mm

103x46x26mm

M4

EM-Tec R2-1.5

12-006258

Ø1-1/2”

2

20mm

yes / yes

88x38mm

103x46x26mm

Ø14mm JEOL

EM-Tec R22

12-002249

Ø40mm

4

20mm

yes / yes

88x85mm

103x92x30mm

3.2mm pin stub

EM-Tec R22

12-003249

Ø40mm

4

20mm

yes / yes

88x85mm

103x92x30mm

M4

EM-Tec R22

12-006249

Ø40mm

4

20mm

yes / yes

88x85mm

103x92x30mm

Ø14mm JEOL

EM-Tec R22-1.5

12-003259

Ø1-1/2”

4

20mm

yes / yes

88x83mm

103x92x30mm

3.2mm pin stub

EM-Tec R22-1.5

12-003359

Ø1-1/2”

4

20mm

yes / yes

88x83mm

103x92x30mm

M4

EM-Tec R22-1.5

12-006259

Ø1-1/2”

4

20mm

yes / yes

88x83mm

103x92x30mm

Ø14mm JEOL

EM-Tec R5

12-003256

Ø50mm/ 2”

2

26mm

yes / yes

108x51mm

125x57x32mm

3.2mm pin stub

EM-Tec R5

12-003356

Ø50mm/ 2”

2

26mm

yes / yes

108x51mm

125x57x32mm

M4

EM-Tec R5

12-006256

Ø50mm/ 2”

2

26mm

yes / yes

108x51mm

125x57x32mm

Ø14mm JEOL

EM-Tec R7

12-003257

49 x 89mm

2

26mm

yes / yes

108x51mm

125x57x32mm

3.2mm pin stub

EM-Tec R7

12-003357

49 x 89mm

2

26mm

yes / yes

108x51mm

125x57x32mm

M4

EM-Tec R7

12-006257

49 x 89mm

2

26mm

yes / yes

108x51mm

125x57x32mm

Ø14mm JEOL



Ordering information:
