Silver coated silicon wafers
Nano-Tec silver coated silicon wafers are useful for applications such as thin film research, AFM / SPM, nanotechnology, reflectometry and optical applications. The silicon wafers are coated with pure silver over an adhesion layer of Ti. Both Ti and Ag are deposited in a dedicated high vacuum deposition system with electron beam (EB) evaporation sources. The silver coating is not atomically flat – there are height differences in the nm range.
The available silver coating thicknesses are: 10 nm, 50 nm, 100 nm and 500 nm. Available in three silicon wafer sizes: Ø2”/51mm, 3”/76mm and Ø4”/100mm). The Nano-Tec silver coated wafers are individually packed in wafer carrier trays for protection.
Specifications of Nano-Tec silver coater silicon wafers
|
Silver coating |
||||
|
Coating film Ag, 99.99% purity |
10 nm |
50 nm |
100nm |
500nm |
|
Adhesion film Ti, 99.98% purity |
2 nm |
5 nm |
5 nm |
7.5 nm |
|
Surface roughness |
Several nm |
|||
|
Si wafer substrate |
|||
|
Si substrate orientation |
<100> |
||
|
Si wafer type |
P (Boron) with one primary flat |
||
|
Resistance |
1-30 Ohm/cm |
||
|
Si wafer size |
Ø 2”/51 mm |
Ø3”/76mm |
Ø4”/100mm |
|
Si wafer thickness |
275µm (+/- 25µm) |
381µm (+/- 25µm) |
525µm (+/- 20µm) |
|
TTV |
=< 20µm |
=< 20µm |
=< 20µm |
|
Primary flat |
15.9 +/- 1.65mm |
22.2 +/- 3.17mm |
|
Ordering information:
Silicon wafers with 10nm of silver coating
-
Carbon on 200 mesh Au (50)
Carbon support film on 200 mesh Au (50)
£149.82 Add to basket -
Silver coated Si wafer, Ø3inch/76mm, 381um thick, 10nm Ag
Nano-Tec silver coated silicon wafer, Ø3inch/76mm, 381um thickness, 10nm Ag (Pk/5)
£748.92 Add to basket -
Silver coated silicon wafer, Ø2”/51mm, 275µm thick, 10nm Ag
Nano-Tec silver coated silicon wafer, Ø2inch/51mm, 275um thickness, 10nm Au (Pk/5)
£788.04 Read more -
Silver coated silicon wafer, Ø4”/100mm, 5255µm thick, 10nm Ag
Nano-Tec silver coated silicon wafer, Ø4inch/100mm, 525um thickness, 10nm Au (Pk/5)
£755.43 Read more
Silicon wafers with 50nm of silver coating
-
Silver coated Si wafer, Ø3inch/76mm, 381um thick, 50nm Ag
Nano-Tec silver coated silicon wafer, Ø3inch/76mm, 381um thickness, 50nm Ag (Pk/5)
£781.25 Add to basket -
Silver coated Si wafer, Ø4inch/100mm, 525um thick, 50nm Ag
Nano-Tec silver coated silicon wafer, Ø4inch/100mm, 525um thickness, 50nm Ag (Pk/3)
£781.25 Add to basket -
Silver coated Si wafer, Ø3inch/76mm, 275um thick, 50nm Ag
Nano-Tec silver coated silicon wafer, Ø3inch/76mm, 275um thickness, 50nm Ag (Pk/5)
£802.80 Add to basket -
Silver coated Si wafer, Ø3inch/76mm, 275um thick, 50nm Ag
Nano-Tec silver coated silicon wafer, Ø3inch/76mm, 275um thickness, 50nm Ag (Pk/5)
£802.80 Add to basket
Silicon wafers with 100nm of silver coating
-
Silver coated Si wafer, Ø3inch/76mm, 381um thick, 100nm Ag
Nano-Tec silver coated silicon wafer, Ø3inch/76mm, 381um thickness, 100nm Ag (Pk/5)
£862.07 Add to basket -
Silver coated Si wafer, Ø4inch/100mm, 525um thick, 100nm Ag
Nano-Tec silver coated silicon wafer, Ø4inch/100mm, 525um thickness, 100nm Ag (Pk/3)
£862.05 Add to basket -
Silver coated Si wafer, Ø3inch/76mm, 275um thick, 100nm Ag
Nano-Tec silver coated silicon wafer, Ø3inch/76mm, 275um thickness, 100nm Ag (Pk/5)
£899.78 Read more
Silicon wafers with 500nm of silver coating
-
Silver coated Si wafer, Ø3inch/76mm, 381um thick, 500nm Ag
Nano-Tec silver coated silicon wafer, Ø3inch/76mm, 381um thickness, 500nm Ag (Pk/5)
£1,018.32 Add to basket -
Silver coated Si wafer, Ø4inch/100mm, 525um thick, 500nm Ag
Nano-Tec silver coated silicon wafer, Ø4inch/100mm, 525um thickness, 500nm Ag (Pk/3)
£1,018.32 Add to basket -
Silver coated Si wafer, Ø3inch/76mm, 275um thick, 500nm Ag
Nano-Tec silver coated silicon wafer, Ø3inch/76mm, 275um thickness, 500nm Ag (Pk/5)
£1,050.65 Read more
